Front:
CYLINDERS (4)
BOILER
FIREBOX
TUBES
FIRE
TENDER
CAERPHILLY CASTLE
HEATING SURFACE
AREA OF FIREGRATE
WHEELS.
WATER CAPACITY OF
3500 GALLONS.
4073 ("CASTLE") CLASS. TYPE 4-6-0.
DIAM. 16 INS. STROKE 26 INS.
BARREL 14 FT. 10 IN. DIAM., OUTS. 5 FT. 9 INS. & 5 FT. 115/16. IN.
5 01/8
LENGTH 15 FT. 33/8 INS.
OUTS, 10 FT. X FT: INS. 9 FT. 27/16 INS. X 3 FT: 25/8 IN: HEIGHT 6 FT. 87/8 IN. & 5 FT. 37.8 INS.
(SUPERHEATER TUBES No. 84. DIAM. 1 IN.
201.
2 IN.
(SUPERHEATER TUBES 1 IN. 262 62 SQ. FT.
1885 62 ..
163 76.
No. 14. DIAM. 51/8 INS. LENGTH 15 FT. 27/16 IN.
TOTAL 2312'0 SQ. FT.
TOTAL
2049.38 SQ. FT.
FIRE
FIREBOX
30 28 SQ. FT.
BOGIE 3 FT. 2 INS. COUPLED 6 FT. 81/2 INS.
WORKING PRESSURE
4073
GREAT
225 LBS. SQ. INS.
GREAT WESTERN RAILWAY.
TRACTIVE EFFORT
38C. 19
EFF
31625 LBS.
Back:
VALENTINE'S
THROUGHOUT
THIS IS A REAL PHOTOGRAPH
38-2
GREAT BRITAIN
